前言

CentOS7开机启动自定义脚本大致分为以下几种方式：

通过CentOS7的rc-local服务启动
使用CentOS7 systemctl 添加系统服务自启动
通过Linux下的chkconfig添加系统启动脚本

systemd自定义服务自启动

Nginx自启动

配置服务文件

在/lib/systemd/system下创建并编辑nginx.service

[root@localhost ~]# cd /lib/systemd/system
[root@localhost ~]# touch nginx.service
[root@localhost ~]# vim nginx.service

[Unit]
#描述服务
Description=nginx
#描述服务在指定服务周后启动
After=network.target

#服务运行参数的设置，注意【Service】的启动、重启、停止命令都要用绝对路径
[Service]
#后台运行的形式
Type=forking
#服务具体运行的命令
ExecStart=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/nginx.conf
#重启命令
ExecReload=/usr/local/nginx/sbin/nginx -s reload
#停止命令
ExecStop=/usr/local/nginx/sbin/nginx -s quit
#表示给服务分配独立的临时空间
PrivateTmp=true

#运行级别下服务安装的相关设置，可设置为多用户，即系统运行级别为3
[Install]
WantedBy=multi-user.target

重新加载服务配置文件

[root@localhost ~]# systemctl daemon-reload

测试服务配置

[root@localhost ~]# systemctl start nginx.service
[root@localhost ~]# systemctl restart nginx.service
[root@localhost ~]# systemctl stop nginx.service

加入自启动

[root@localhost ~]# systemctl enable nginx.service

Redis自启动

配置服务文件

在/lib/systemd/system下创建并编辑redis.service

[root@localhost ~]# cd /lib/systemd/system
[root@localhost ~]# touch redis.service
[root@localhost ~]# vim redis.service

[Unit]
#描述服务
Description=redis
#描述服务在指定服务周后启动
After=network.target

#服务运行参数的设置，注意【Service】的启动、重启、停止命令都要用绝对路径
[Service]
#后台运行的形式
Type=forking
#服务具体运行的命令
ExecStart=/usr/local/bin/redis-server /etc/redis/6379.conf
#重启命令
ExecReload=/usr/local/nginx/sbin/nginx -s reload
#停止命令
ExecStop=/usr/local/bin/redis-cli -h 127.0.0.1 -p 6379 shutdown
#表示给服务分配独立的临时空间
PrivateTmp=true

#运行级别下服务安装的相关设置，可设置为多用户，即系统运行级别为3
[Install]
WantedBy=multi-user.target

重新加载服务配置文件

[root@localhost ~]# systemctl daemon-reload

测试服务配置

[root@localhost ~]# systemctl start redis.service
[root@localhost ~]# systemctl restart redis.service
[root@localhost ~]# systemctl stop redis.service

加入自启动

[root@localhost ~]# systemctl enable redis.service

RocketMQ自启动

mqnamesrv自启动

配置文件rocketmq-ns.service：

[Unit]

Description=RocketMQ Namesrv
After=network.target remote-fs.target nss-lookup.target
Before=rocketmq-bk.service

[Service]
Type=simple
User=root
ExecStart=/home/rocketmq/bin/mqnamesrv
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-ns

[Install]
WantedBy=multi-user.target

broker自启动

配置文件rocketmq-bk.service：

[Unit]
Description=rocketmq-broker
After=network.target rocketmq-ns.service

[Service]
Type=sample
User=root
ExecStart=/home/rocketmq/bin/mqbroker -c /home/rocketmq/conf/broker.conf
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-bk

[Install]
WantedBy=multi-user.target

Frp客户端服务自启动

配置文件frpc.service：

[Unit]
Description=Frp Client Service
After=network.target mose-api.target
Wants=mose-api.service

[Service]
Type=simple
User=nobody
Restart=on-failure
RestartSec=5s
ExecStart=/usr/bin/frpc -c /etc/frp/frpc.ini
ExecReload=/usr/bin/frpc reload -c /etc/frp/frpc.ini
LimitNOFILE=1048576

[Install]
WantedBy=multi-user.target

Java（jar包）服务自启动

Api服务自启动

配置文件mose-api.service：

[Unit]
Description=mose-api-serve
After=network.target rocketmq-bk.service mose-job.service
Wants=mose-job.service
Requires=rocketmq-bk.service

[Service]
Type=simple
User=root
ExecStart=/home/soft/jdk/bin/java -XX:MetaspaceSize=256m -XX:MaxMetaspaceSize=256m -Xms2048m -Xmx2048m -Xmn512m -Xss512m -XX:SurvivorRatio=8 -jar -Dspring.profiles.active=test /home/server_space/ucd/mose-admin.jar
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-api

[Install]
WantedBy=multi-user.target

Job服务自启动

配置文件mose-job.service：

[Unit]
Description=mose-job-serve
After=network.target

[Service]
Type=simple
User=root
ExecStart=/home/soft/jdk/bin/java -XX:MetaspaceSize=128m -XX:MaxMetaspaceSize=128m -Xms1024m -Xmx1024m -Xmn256m -Xss256m -XX:SurvivorRatio=8 -jar -Dspring.profiles.active=test /home/server_space/ucd/xxl-job-admin.jar
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-job
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target

输出日志到自定义文件

配置日志输出策略

新建rsyslog日志处理服务转发策略

[root@localhost system]# cd /etc/rsyslog.d/
[root@localhost rsyslog.d]# ls
listen.conf
[root@localhost rsyslog.d]# touch moseApi.conf
[root@localhost rsyslog.d]# touch moseJob.conf
[root@localhost rsyslog.d]# touch rocketmqNS.conf
[root@localhost rsyslog.d]# touch rocketmqBK.conf
[root@localhost rsyslog.d]# vim moseApi.conf
[root@localhost rsyslog.d]# vim moseJob.conf
[root@localhost rsyslog.d]# vim rocketmqNS.conf
[root@localhost rsyslog.d]# vim rocketmqBK.conf
[root@localhost rsyslog.d]# ls
listen.conf  moseApi.conf  moseJob.conf  rocketmqBK.conf  rocketmqNS.conf
[root@localhost rsyslog.d]#

#moseApi.conf内容
if $programname == 'mose-api' then /home/server_space/ucd/mose-admin.log
& :omusrmsg:stopp

#moseJob.conf内容
if $programname == 'mose-job' then /home/server_space/ucd/xxl-job-admin.log
& :omusrmsg:stopp

#rocketmqNS.conf内容
if $programname == 'rocketmq-ns' then /var/log/rocketmq-namesrv.log
& :omusrmsg:stopp

#rocketmqBK.conf内容
if $programname == 'rocketmq-bk' then /var/log/rocketmq-broker.log
& :omusrmsg:stopp

重启日志rsyslog服务

[root@localhost system]# systemctl restart rsyslog.service

指定服务日志处理方式

修改服务配置文件

[root@localhost system]# vim mose-api.service
[root@localhost system]# vim mose-job.service
[root@localhost system]# vim rocketmq-ns.service
[root@localhost system]# vim rocketmq-bk.service

#mose-api.service变更内容
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-api

#mose-job.service变更内容
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-job

#rocketmq-ns.service变更内容
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-ns

#rocketmq-bk.service变更内容
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-bk

刷新服务配置文件

[root@localhost system]# systemctl daemon-reload

测试日志重定向

重启服务

[root@localhost system]# systemctl stop mose-api.service
[root@localhost system]# systemctl start mose-api.service

查看日志

[root@localhost system]# tail -200f /home/server_space/ucd/mose-admin.log

问题分析解决

问题：发现日志并未重定向写入 /home/server_space/ucd/mose-admin.log 下

查看系统日志

[root@localhost system]# tail -1000f /var/log/message

May 29 20:32:56 localhost mose-job: Copyright @ 2021-2099 bjucd.com All Rights Reserved.
May 29 20:32:56 localhost rsyslogd: action 'action 2' resumed (module 'builtin:omfile') [v8.24.0-55.el7 try http://www.rsyslog.com/e/2359 ]
May 29 20:32:56 localhost rsyslogd: file '/home/server_space/ucd/xxl-job-admin.log': open error: Permission denied [v8.24.0-55.el7 try http://www.rsyslog.com/e/2433 ]

文件赋予权限重试

[root@localhost system]# chomd -R 755 /home/server_space/ucd/xxl-job-admin.log

问题依然存在，网络查找
- 发现是selinux 开启导致rsyslog 打开文件失败
- 关闭selinux 后重启服务器测试，日志可以重定向写入
- 由于自定义的路径的context不满足rsyslogd的访问权限，所以被selinux禁止访问了
- 最终解决方案

最终服务配置

RocketMQ自启动

mqnamesrv配置

[Unit]

Description=RocketMQ Namesrv
After=network.target remote-fs.target nss-lookup.target
Before=rocketmq-bk.service

[Service]
Type=simple
User=root
ExecStart=/home/rocketmq/bin/mqnamesrv
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-ns

[Install]
WantedBy=multi-user.target

broker配置

[Unit]
Description=rocketmq-broker
After=network.target rocketmq-ns.service

[Service]
Type=sample
User=root
ExecStart=/home/rocketmq/bin/mqbroker -c /home/rocketmq/conf/broker.conf
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=rocketmq-bk

[Install]
WantedBy=multi-user.target

Java（jar包）服务自启动

Api配置

[Unit]
Description=mose-api-serve
After=network.target rocketmq-bk.service mose-job.service
Wants=mose-job.service
Requires=rocketmq-bk.service

[Service]
Type=simple
User=root
ExecStart=/home/soft/jdk/bin/java -XX:MetaspaceSize=256m -XX:MaxMetaspaceSize=256m -Xms2048m -Xmx2048m -Xmn512m -Xss512m -XX:SurvivorRatio=8 -jar -Dspring.profiles.active=test /home/server_space/ucd/mose-admin.jar
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
LimitNOFILE=65536

StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-api

[Install]
WantedBy=multi-user.target

Job配置

[Unit]
Description=mose-job-serve
After=network.target

[Service]
Type=simple
User=root
ExecStart=/home/soft/jdk/bin/java -XX:MetaspaceSize=128m -XX:MaxMetaspaceSize=128m -Xms1024m -Xmx1024m -Xmn256m -Xss256m -XX:SurvivorRatio=8 -jar -Dspring.profiles.active=test /home/server_space/ucd/xxl-job-admin.jar
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s QUIT $MAINPID
Restart=0
StandardOutput=syslog
StandardError=syslog
SyslogIdentifier=mose-job
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target

systemd运行服务配置详解

图片防失效

rc.local服务自启动执行脚本

创建启动脚本jenkins_auto.sh

#!/bin/sh
#chkconfig: 2345 80 90
#description: 开机自启动jenkins服务

export JAVA_HOME=/home/soft/jdk
export JRE_HOME=${JAVA_HOME}/jre
export CLASSPATH=.:${JAVA_HOME}/lib/dt.jar:${JAVA_HOME}/lib/tool.jar
export PATH=${JAVA_HOME}/bin:$PATH

sleep 10

nohup java -Dhudson.util.ProcessTree.disable=true -Xms10240m -Xmx10240m -jar /home/jenkins/jenkins.war --httpPort=10086 > /home/jenkins/jenkins.log 2>&1 &

赋予脚本执行权限

[root@localhost init.d]# chmod +x /etc/rc.d/init.d/jenkins_auto.sh

为脚本赋予自启动权限

[root@localhost init.d]# vim /etc/rc.d/rc.local

#!/bin/bash
# THIS FILE IS ADDED FOR COMPATIBILITY PURPOSES
#
# It is highly advisable to create own systemd services or udev rules
# to run scripts during boot instead of using this file.
#
# In contrast to previous versions due to parallel execution during boot
# this script will NOT be run after all other services.
#
# Please note that you must run 'chmod +x /etc/rc.d/rc.local' to ensure
# that this script will be executed during boot.

touch /var/lock/subsys/local
/etc/rc.d/init.d/jenkins_auto.sh
~                                                                                                                                  ~

为rc.local赋予执行权限

CentOS7默认为rc.local降级了，所以给他开开执行权限

[root@localhost init.d]# chmod +x /etc/rc.d/rc.local

查看rc-local服务

如果rc-local服务是停止的，则启动rc-local服务并查看jenkins脚本是否随着自启动jenkins的Jar包
如果rc-local服务是启动的，则杀掉jenkins服务进程，重启rc-local服务并验证jenkins的Jar包是否随着自启动

[root@localhost init.d]# systemctl status rc-local
● rc-local.service - /etc/rc.d/rc.local Compatibility
   Loaded: loaded (/usr/lib/systemd/system/rc-local.service; static; vendor preset: disabled)
   Active: active (running) since 二 2023-05-30 15:03:06 CST; 45min ago
  Process: 1830 ExecStart=/etc/rc.d/rc.local start (code=exited, status=0/SUCCESS)
 Main PID: 3045 (java)
    Tasks: 108
   CGroup: /system.slice/rc-local.service
           └─3045 java -Dhudson.util.ProcessTree.disable=true -Xms10240m -Xmx10240m -jar /home/jenkins/jenkins.war --httpPort=10086

5月 30 15:02:56 localhost.localdomain systemd[1]: Starting /etc/rc.d/rc.local Compatibility...
5月 30 15:03:06 localhost.localdomain systemd[1]: Started /etc/rc.d/rc.local Compatibility.
[root@localhost init.d]#

[root@localhost init.d]# ps -ef | grep jenkins
root      3045     1  3 15:03 ?        00:01:48 java -Dhudson.util.ProcessTree.disable=true -Xms10240m -Xmx10240m -jar /home/jenkins/jenkins.war --httpPort=10086
root     74420 47111  0 15:52 pts/2    00:00:00 grep --color=auto jenkins
[root@localhost init.d]# kill -9 3045
[root@localhost init.d]# ps -ef | grep jenkins
root     74985 47111  0 15:53 pts/2    00:00:00 grep --color=auto jenkins
[root@localhost init.d]# systemctl restart rc-local
[root@localhost init.d]# tail -f /home/jenkins/jenkins.log
2023-05-30 07:53:53.257+0000 [id=1]     INFO    o.e.j.s.handler.ContextHandler#doStart: Started w.@7927bd9f{Jenkins v2.361.1,/,file:///root/.jenkins/war/,AVAILABLE}{/root/.jenkins/war}
2023-05-30 07:53:53.278+0000 [id=1]     INFO    o.e.j.server.AbstractConnector#doStart: Started ServerConnector@16022d9d{HTTP/1.1, (http/1.1)}{0.0.0.0:10086}
2023-05-30 07:53:53.289+0000 [id=1]     INFO    org.eclipse.jetty.server.Server#doStart: Started Server@290dbf45{STARTING}[10.0.11,sto=0] @1631ms
2023-05-30 07:53:53.291+0000 [id=49]    INFO    winstone.Logger#logInternal: Winstone Servlet Engine running: controlPort=disabled
2023-05-30 07:53:53.530+0000 [id=55]    INFO    jenkins.InitReactorRunner$1#onAttained: Started initialization
2023-05-30 07:53:53.764+0000 [id=121]   INFO    jenkins.InitReactorRunner$1#onAttained: Listed all plugins
2023-05-30 07:53:56.929+0000 [id=179]   INFO    jenkins.InitReactorRunner$1#onAttained: Prepared all plugins
2023-05-30 07:53:56.941+0000 [id=124]   INFO    jenkins.InitReactorRunner$1#onAttained: Started all plugins
2023-05-30 07:53:56.950+0000 [id=132]   INFO    jenkins.InitReactorRunner$1#onAttained: Augmented all extensions
2023-05-30 07:53:57.391+0000 [id=124]   INFO    h.p.b.g.GlobalTimeOutConfiguration#load: global timeout not set
2023-05-30 07:53:58.034+0000 [id=146]   INFO    jenkins.InitReactorRunner$1#onAttained: System config loaded
2023-05-30 07:53:58.036+0000 [id=159]   INFO    jenkins.InitReactorRunner$1#onAttained: System config adapted
2023-05-30 07:53:58.112+0000 [id=166]   INFO    jenkins.InitReactorRunner$1#onAttained: Loaded all jobs
2023-05-30 07:53:58.130+0000 [id=58]    INFO    jenkins.InitReactorRunner$1#onAttained: Configuration for all jobs updated
2023-05-30 07:53:58.143+0000 [id=197]   INFO    hudson.model.AsyncPeriodicWork#lambda$doRun$1: Started Download metadata
2023-05-30 07:53:58.150+0000 [id=197]   INFO    hudson.util.Retrier#start: Attempt #1 to do the action check updates server
2023-05-30 07:53:58.207+0000 [id=61]    INFO    jenkins.InitReactorRunner$1#onAttained: Completed initialization
2023-05-30 07:53:58.275+0000 [id=40]    INFO    hudson.lifecycle.Lifecycle#onReady: Jenkins is fully up and running
^C
[root@localhost init.d]# ps -ef | grep jenkins
root     76699     1 99 15:53 ?        00:00:49 java -Dhudson.util.ProcessTree.disable=true -Xms10240m -Xmx10240m -jar /home/jenkins/jenkins.war --httpPort=10086
root     77567 47111  0 15:54 pts/2    00:00:00 grep --color=auto jenkins
[root@localhost init.d]#

如果自启动失败，可以查看/var/log/message日志

设置rc-local服务自启动

[root@localhost init.d]# systemctl enable rc-local

通过chkconfig添加系统启动脚本

在CentOS7之前，可以通过chkconfig来配置开机自启动服务

chkconfig –-add xxx   #把服务添加到chkconfig列表
chkconfig --del xxx   #把服务从chkconfig列表中删除
chkconfig xxx on      #开启开机自动启动
chkconfig xxx off     #关闭开机自动启动
chkconfig --list      #查看所有chklist中服务
chkconfig --list xxx  #查看指定服务

在/etc/rc.d/init.d下新增脚本run.sh

#!/bin/bash
#chkconfig: 2345 80 90
#description: 开机自启动jenkins服务

export JAVA_HOME=/home/soft/jdk
export JRE_HOME=${JAVA_HOME}/jre
export CLASSPATH=.:${JAVA_HOME}/lib/dt.jar:${JAVA_HOME}/lib/tool.jar
export PATH=${JAVA_HOME}/bin:$PATH

sleep 10

nohup java -Dhudson.util.ProcessTree.disable=true -Xms10240m -Xmx10240m -jar /home/jenkins/jenkins.war --httpPort=10086 > /home/jenkins/jenkins.log 2>&1 &

增加脚本的可执行权限

[root@localhost init.d]# chmod +x /etc/rc.d/init.d/run.sh

添加脚本到开机自动启动项目中

[root@localhost init.d]# cd /etc/rc.d/init.d
[root@localhost init.d]# chkconfig --add run.sh
[root@localhost init.d]# chkconfig run.sh on

CentOS7-设置开机自启动

前言

systemd自定义服务自启动

Nginx自启动

配置服务文件

重新加载服务配置文件

测试服务配置

加入自启动

Redis自启动

配置服务文件

重新加载服务配置文件

测试服务配置

加入自启动

RocketMQ自启动

mqnamesrv自启动

broker自启动

Frp客户端服务自启动

Java（jar包）服务自启动

Api服务自启动

Job服务自启动

输出日志到自定义文件

配置日志输出策略

指定服务日志处理方式

测试日志重定向

问题分析解决

最终服务配置

RocketMQ自启动

mqnamesrv配置

broker配置

Java（jar包）服务自启动

Api配置

Job配置

systemd运行服务配置详解

rc.local服务自启动执行脚本

创建启动脚本jenkins_auto.sh

赋予脚本执行权限

为脚本赋予自启动权限

为rc.local赋予执行权限

查看rc-local服务

设置rc-local服务自启动

通过chkconfig添加系统启动脚本

在/etc/rc.d/init.d下新增脚本run.sh

增加脚本的可执行权限

添加脚本到开机自动启动项目中

评论区
